LL RDMX
Attention Please
Complete and submit the information requested in the form below. Our agent will get back to you as soon as possible.
Description
Product & Power Options
| Product Name | Light Color | Input Voltage (V) | Power (W) | Dimensions (mm) | LED Quantity (pcs.) | Pixel Pitch (cm) |
|---|---|---|---|---|---|---|
| LL-RDMX-10-4x2,5 | RGB | 15-48V DC | 2 | 102 | 4 | 4x2,5 |
| LL-RDMX-50-4x2,5 | RGB | 15-48V DC | 6 | 502 | 20 | 4x2,5 |
| LL-RDMX-100-4x2,5 | RGB | 15-48V DC | 11 | 1002 | 40 | 4x2,5 |
| LL-RDMX-150-4x2,5 | RGB | 15-48V DC | 16 | 1502 | 60 | 4x2,5 |
Key Features
ELECTROMECHANICAL SPECIFICATIONS
• Min. 20 micron anodized aluminyum extruded profile
• Stainless connectors
• PVC side cover with UV protection
• UV protective diffused front cover
• Cooling capacity up to 36W/m
• Suitable for surface mounting
• Each piece can be produced at a max. lenght of 4m
• RDM configuraion
• IP67 socket for DATA-SIGNALS
Accessories
33400474 : CABLE 2X0,22 KR-SY LI2Y(ST)CH TP GREY
26000122 : SOCKET RDMX L:100cm 4 PIN MALE-FEMALE DOUBLE SIDED EXTENSION IP67 (YM)
26000150 : SOCKET RDMX L:200cm 4 PIN MALE-FEMALE DOUBLE SIDED EXTENSION IP67 (YM)
26000151 : SOCKET RDMX L:400cm 4 PIN MALE-FEMALE DOUBLE SIDED EXTENSION IP67 (YM)
26000152 : SOCKET RDMX L:600cm 4 PIN MALE-FEMALE DOUBLE SIDED EXTENSION IP67 (YM)
26000153 : SOCKET RDMX L:800cm 4 PIN MALE-FEMALE DOUBLE SIDED EXTENSION IP67 (YM)
26000154 : SOCKET RDMX L:1000cm 4 PIN MALE-FEMALE DOUBLE SIDED EXTENSION
Connection Options
COMBINED MODEL CONNECTION SCHEME
CONNECTION SCHEME WITH EXTENSION SOCKET
RDMX INPUT JUNCTION BOX
STANDARD CONNECTION SCHEME
DOT TERMINATOR
(1) DMX DATA CABLE, 33400474 : CABLE 2X0,22 KR-SY LI2Y(ST)CH TP GREY
(2) AC SUPPLY CABLE, 3x1mm TTR
(3) 26000xxx : SOCKET RDMX L:100/200/400/600/800/1000cm 4 PIN MALE-FEMALE DOUBLE SIDED EXTENSION IP67 (YM)
(4) 33600695 :RDMX INPUT JUNCTION BOX
(5) 33600696 : RDMX TERMINATOR
Upper Piece Options
01. DIFFUSE COVER
02. FLAT DIFFUSE
03. FLAT POLYMER COVER
Technical Draw
