Description
Product & Power Options
| Product Code | LIGHT COLOR | INPUT VOLTAGE (V) | Power | Luminous Flux | Dimensions(A) | Bore (C) Diameter | Weight (KG) |
|---|---|---|---|---|---|---|---|
| CDEW3-TECO | WW-NW-CW | 220-240V AC | 5 | 450 | Ø95X45mm | Ø80mm | 0,3kg |
| CDEW4-TECO | WW-NW-CW | 220-240V AC | 10 | 900 | Ø120X49mm | Ø105mm | 0,4kg |
| CDEW6-TECO | WW-NW-CW | 220-240V AC | 18 | 1620 | Ø177X55mm | Ø155mm | 0,6kg |
| CDEW8-TECO | WW-NW-CW | 220-240V AC | 28 | 2520 | Ø228X58mm | Ø205mm | 0,9kg |
*Power and Lumen values provided are based off of a cold white (CW) LED.
Key Features
ELECTROMECHANICAL SPECIFICATIONS
• Electrostatic painted aluminum injection body and frame
• Low-glare (UGR 19) homogeneous light
• Stainless spring system for ceiling mounting
• Suitable for recessed mounting
Light Color Options
Driver Options
Control System Options
| Color Type | PWM | INW PWM | DMX | DALI | 0 - 10V DC | TRIAC | |
|---|---|---|---|---|---|---|---|
| WW-NW-CW | |||||||
| R,G,B,A | |||||||
| RGB |  |
||||||
| RGBA/W |
  |
||||||
| RGB DMX |
 |
||||||
| WHITE DMX |
 |
||||||
Housing Color Options
RAL9005
RAL9007
RAL9016
